for Honda B16 B18 Engine Motor T3T4 Turbocharger Kit

B16 B18 DOHC VTEC Motor Turbocharger Kit

Compatibility:

• Honda B-Series Engine Motor B16 B18

Kit Includes:

• TX-50E-57 .63 A/R Turbocharger
• Intercooler 27x6.5x3 (Direct Bolt-On)
• 2.25" Aluminized Mandrel Bent Piping (Total of 4)
• High Pressure Silicon Hose (Total of 6)
• Clamps (Total of 21)
• Cast Iron Turbo Manifold
• 2.5" Stainless Steel Down pipe
• Stainless Steel Connect Pipe
• Stainless Steel Dump Pipe
• Blow Off Valve
• 38mm Wastegate (Set at 5PSI) Comes With Extra 10 PSI Spring In Order To Make 15 PSI Maximum Setting.
• Valve Set for Wastegate
• Gasket Kit for Wastegate
• Steel Braided Oil Feed Line
• Oil Return Line
• Oil Pan Fitting
• Necessary Vacuum Tees
• Necessary Vacuum Lines
• Necessary Gaskets and Bolts
• Necessary Hardware
• Air Filter Color May Vary

Specifications:

TX-50E Turbocharger .63 AR

Compressor Inlet: 3.00"
Compressor Outlet: 2.00"
Compressor Cover: TX-50E Cover
Compressor Wheel Diameter: 53mm / 75mm
Turbine Wheel Diameter: 57mm / 65mm
Exhaust Trim: .63 AR
Turbine Flange Type: T3 Flange
Downpipe Flange Type: 5-Bolt Standard Type
Cooling Type: Oil Cooled Only
Horsepower Rating: 200-400 HP+
